Box Jellyfish- For your eyes only

by Matthew Norton

When we think of box jellyfish it is their deadly sting, easily fatal to humans if not treated quickly, that comes to mind. What is less well known is their remarkably complex visual system, for such a simple organism, with a grand total of 24 eyes arranged among four sensory clubs, called rhopalia.

(Rev) box jellyfish article image 1
Box jellyfish (class Cubozoa) are characterised by their cube shaped bodies and like their fellow Cnidarian invertebrates (eg. corals, anemones and other jellyfish) they possess stinging cells.

Many organisms are able to detect light, even when they can’t actually ‘see’ the world around them, when it is absorbed by light sensitive pigments embedded. The chemical reaction that is triggered produces an electrical signal that tells the organism that light has been detected.

But within each rhopalium of a box jellyfish, there are distinct eye types that include a pair of eye pits and a pair of eye slits. Both of which contain light sensitive pigments, and an upper and lower camera lens eye. The simple structure of the pit and slit eyes suggest that their primary function is detecting and monitoring the level of light in their surroundings. However the discovery of a lens-like structure in the slit eyes may suggest that they may have some limited ability to interpret images of the world around them.

(Rev) box jellyfish article image 2
Box jellyfish, Tripedalia cystophora, and a single rhopalium with four labelled eye types. Eye pits (PE), eye slits (SE), upper camera lens eye (ULE) and lower camera lens eye (LLE).

Both camera lens eyes are similar in structure to the eyes of many vertebrate animals (including humans). Theoretically we could say that box jellyfish can ‘see’ the world around them, although the ‘quality’ of their sight is likely to be very limited compared to our own, for two very good reasons. Firstly, the lens is too close to the retina, thus inhibiting their ability to focus images, and secondly, it is doubtful that the box jellyfish’s simple nervous system has the processing power to produce a coherent image.

(Rev) box jellyfish article image 3
In the human eye light is absorbed by the retina, which contains many light sensitive pigments, the electrical signals are transmitted along the optic nerve and are processed by the visual cortex of the brain. Due to the small eye opening a lens is also required to alter the direction that the incoming light travel (light refraction) so that the whole retina can be exposed to light. The lens can also change shape, and thus change how much the light is refracted, so that the image can focused.

Despite these limitations the complex eye arrangement is still put to good use, helping box jellyfish perform visually guided behaviours such as avoiding obstacles and altering swimming speed and direction in response to changes in light intensity. Each rhopalium helps to guide these behaviours by transmitting electrical signals, nicknamed “swim pacemaker signals”, which directly control swimming contractions.

Furthermore observations from some species suggest that box jellyfish could also see in colour. For example the camera lens eyes of Tripedalia cystophora are especially sensitive to blue-green light, and Chironex fleckeri has shown a curious ‘figure eight’ swimming pattern in response to blue light. In theory colour vision would also be very useful to box jellyfish in shallow water as glare from the water surface could confuse any creature that relies on changes in light intensity to see, whereas the contrast between different colours would be unaffected.

(Rev) box jellyfish article image 4
Both Tripedalia cystophora (left) and Chironex fleckeri (right) are thought to be able to see in colour.
(Rev) box jellyfish article image 5
Colour vision requires multiple types of pigments that are sensitive to different colours of light, for example the human eye contains red, green and blue light sensitive pigments. The light absorbed by these three pigments combined allows us to perceive a wide variety of colours.

However, there are convincing counterarguments. In most species the camera lens eyes only possess one type of light sensitive pigment which, despite being sensitive to a particular colour of light, still leaves them colour blind. Also, the idea that it helps to overcome surface water glare is a very general theory on the evolution of colour vision and may be more applicable to other animals. Furthermore, the close proximity of the lens to the retina in the camera lens eyes has been speculated as a possible alternative to overcoming surface water glare.

From a human perspective

The arrangement and capabilities of the many eyes that box jellyfish possess is definitely fascinating, but there are at least two ways in which an understanding of how box jellyfish see the world may benefit us.

Firstly, existing measures to reduce contact with human swimmers (eg. protective clothing, beach warning signs) could be improved by exploiting the visually guided behaviours of box jellyfish. For example the use of dark coloured material in protective wetsuits may increase the likelihood of a box jellyfish perceiving the wearer as an obstacle, and actively avoid them.

(Rev) box jellyfish article image 6
A beach sign in Cape Tribulation, Queensland, Australia warning of box jellyfish.

Secondly the similarities between the human eye and the camera lens eyes of box jellyfish could, in theory, be used to develop treatments for malformations in the former. Some such malformations, such as displaced pupils, have been linked to mutations in a ‘master control gene’ in eye development, Pax6. PaxB, a gene which performs similar functions to Pax6, has been found in the camera lens eye of Tripedalia cystophora, which makes it a potentially useful ‘model species’ to test possible treatments. However, there are still some structural and developmental differences between human and box jellyfish eyes. Therefore Tripedalia cystophora should probably only be used in the early testing stages of such treatments.

(Rev) box jellyfish thanks for reading image
Thanks for reading

Sources

Wikipedia. 2020. Box Jellyfish. https://en.wikipedia.org/wiki/Box_jellyfish. Last accessed 31/10/2017

Garm et al. 2008. Unique structure and optics of the lesser eyes of the box jellyfish Tripedalia cystophora

O’Connor et al. 2009. Structure and optics of the eyes of the box jellyfish Chiropsella bronzie

Nilsson et al. 2005. Advanced optics in a jellyfish eye

Wikipedia. 2020. Lens (anatomy). https://en.wikipedia.org/wiki/Lens_(anatomy). Last accessed 31/10/2017

Wikipedia. 2020. Retina. https://en.wikipedia.org/wiki/Retina. Last accessed 31/10/2017

O’Connor et al. 2010. Visual pigment in the lens eyes of the box jellyfish Chiropsella bronzie

Garm et al. 2007a. The lens eyes of the box jellyfish Tripedalia cystophora and Chiropsalmus sp. are slow and color-blind

Garm et al. 2007b. Visually guided obstacle avoidance in the box jellyfish Tripedalia cystophora and Chiropsella bronzie

Garm and Bielecki 2008. Swim pacemakers in box jellyfish are modulated by the visual input

Buskey. 2003. Behavioral adaptations of the cubozoan medusa Tripedalia cystophora for feeding on copepod (Dioithona oculata) swarms

Piatigorsky and Kozmik. 2004. Cubozoan jellyfish: an Evo/Devo model for eyes and other sensory systems

Petie et al. 2011. Visual control of steering in the box jellyfish Tripedalia cystophora

Hanson et al. 1999. Missense mutations in the most ancient residues of the PAX6 paired domain underlie a spectrum of human congenital eye malformations

Gershwin and Dawes. 2008. Preliminary Observations on the Response of Chironex fleckeri (Cnidaria: Cubozoa: Chirodropida) to Different Colors of Light

Maximov 2000. Environmental factors which may have led to the appearance of colour vision

NHS. 2018. Jellyfish and other sea creature stings. https://www.nhs.uk/conditions/jellyfish-and-other-sea-creature-stings/. Last accessed 31/10/2017

Image sources

Guido Gautsch. 2011. [CC BY-SA 2.0 (https://creativecommons.org/licenses/by-sa/2.0)]. https://commons.wikimedia.org/wiki/File:Avispa_marina_cropped.png

Jan Bielecki, Alexander K. Zaharoff, Nicole Y. Leung, Anders Garm, Todd H. Oakley. 2014. [CC BY 4.0 (https://creativecommons.org/licenses/by/4.0)]. https://commons.wikimedia.org/wiki/File:Cubozoan_visual_system_in_Tripedalia_cystophora.png

Holly Fischer. 2013. [CC BY 3.0 (https://creativecommons.org/licenses/by/3.0)]. https://commons.wikimedia.org/wiki/File:Three_Main_Layers_of_the_Eye.png

Jan Bielecki, Alexander K. Zaharoff, Nicole Y. Leung, Anders Garm, Todd H. Oakley (edited by Ruthven (talk)). 2014. [CC BY-SA 4.0 (https://creativecommons.org/licenses/by-sa/4.0)]. https://commons.wikimedia.org/wiki/File:Tripedalia-cystophora.png

Marc Mongenet. 2005. [CC BY-SA 2.5 (https://creativecommons.org/licenses/by-sa/2.5)]. https://commons.wikimedia.org/wiki/File:16777216colors.png

TydeNet. 2006. [CC BY-SA 3.0 (http://creativecommons.org/licenses/by-sa/3.0/)]. https://commons.wikimedia.org/wiki/File:Marinesting1.jpg

All other images are public domain and do not require attribution
